DCK-11 INNER TEA BAG PACKING MACHINE

SPECIFICATIONS

  • Measuring:Volumetric method
  • Measuring Scope:2.5-10ml about 1.5-5g of broken tea
  • Bag Size:Min. 50×50mm;Max. 65×80(mm)
  • Label Size:Width:28mm;length:25-30mm
  • Packing Speed:30-60bags/minute
  • External Dimensions: 900×950×1800(mm)
  • Machine Weight:About450KG
  • Input Power Supply:220V,50HZ
  • Total Power: 1.6KW
  • Main Motor: 220V、370W、YJ7134Single-phase,1400rpm Heater: 110V、250W、2pce，110V、300W 2pce
  • Control System:About40w
  • Heat-sealed type filtering cotton paper:outer diameter of paper roll≤ ¢ 450mm,inner diameter=¢75mm.
  •  Heat-sealed type label paper:outer diameter of paper roll≤¢300mm,inner diameter=¢75mm,width:28-30mm.
Category: Tags: , , ,

Description

  • This machine is suitable for packing such products as broken tea,coffee,ginseng essence,diet tea,health-caring tea,medicine tea,as well as tea leaves and herbbeverage,etc.
  • The machine can automatically complete such functions as bag-making,filling,measuring,sealing,Thread,feeding,labeling,cutting,counting,etc,t hus reducing labor expenses and improving production efficiency.
